Steam shower

Vista DC130

£17,001

The Tylö Vista Double Corner 130 combines the integrated steam-and-shower system of the standard Vista with additional glazing on both exposed sides, creating a more open enclosure that needs only one fixed wall.

With a 130 x 90 cm footprint, it gives the steam shower a lighter, more freestanding appearance than the standard corner-fit Vista. Tylö’s installation drawings allow left- and right-hand layouts, making it easier to position the door and Stella column around the room.

Inside, the Stella system brings together steam generation, shower controls, Tylö’s Elite control panel and integrated lighting, so the extra openness of the Double Corner design does not change the way the steam shower operates.

Configuration

Double Corner / Left or Right

Dimensions

130 x 90 x 213 cm

Construction

See-Through Glass Enclosure

Steam system

Integrated Stella System

Enquire Now

Book a Showroom Visit

Materials & Construction

More Glass, Fewer Fixed Walls

The Vista Double Corner 130 is designed for installations where the steam shower needs to feel more open within the room. Unlike the standard Vista, which uses two fixed bathroom walls, the Double Corner version requires only one fixed wall and uses additional glazing on the exposed sides.

The enclosure measures 1300 x 900 mm and retains the same 2130 mm overall height as the rest of the Vista range. Large glass panels sit within slim wall, floor and ceiling profiles, with black-coated detailing helping the structure read as one clean architectural element rather than a conventional shower cubicle.

Tylö’s drawings show left- and right-hand layouts, allowing the door and Stella steam column to be positioned around the installation. A dedicated Double Corner shower tray is also available in white or anthracite where a purpose-designed base with integrated drainage is preferred.

Heating & Controls

Steam, Shower and Control in One System

The Vista Double Corner uses the same integrated Stella steam column as the standard Vista models, bringing the steam generator, shower functions and control system together within the enclosure.

The built-in generator is designed for continuous steam production and includes automatic draining and flushing, electronic water-level control, temperature protection and a built-in dirt filter. The system also incorporates Wi-Fi for connected control.

Tylö’s Elite control panel is factory-connected to the Stella relay board and provides control of the steam experience and integrated LED lighting. The shower system uses hot and cold water connections within the column, keeping the main working components concentrated in one unit.

The Specs

Technical Specifications

Product	Tylö Vista Double Corner 130
Type	Double Corner steam shower enclosure
Configuration	Left- or right-hand layout
Width	130 cm
Depth	90 cm
Height	213 cm
Minimum Installation Height	223 cm
Installation	Double Corner installation against one fixed wall
Steam System	Integrated Tylö Stella steam shower system
Control Panel	Tylö Elite
Lighting	Integrated LED lighting
Water Connection	Hot and cold water, 1/2"
Incoming Water Pressure	1-5 bar
Electrical Protection	Maximum 30 mA RCD and multi-pole isolator required
IP Rating	IPX5
Steam Generator Features	Automatic draining, automatic flushing, electronic water-level control and built-in Wi-Fi
Use	Private residential use

Warranty & Aftercare

2 Years

Private residential installations

Warranty cover is subject to correct installation, use and maintenance in accordance with Tylö’s instructions and recommendations.

Hot Tubs Oxfordshire can help with specification, installation planning and ongoing support, so the complete steam-shower system is properly considered from the outset.

Downloadable Resources

Vista Double Corner Installation & User Guide

Download

Vista Double Corner Installation Guide

Download

Why Buy From Hot Tubs Oxfordshire?

Award-Winning Expertise, Lifelong Support

Established wellness retailer
BISHTA member
Hundreds of verified customer reviews
Dedicated showroom experience
Installation guidance and aftercare support

Speak to an Expert

FAQs

What is the Tylö Vista Double Corner 130?

It is a 130 x 90 cm home steam-shower enclosure that combines the integrated Stella steam-and-shower system with additional glazing on both exposed sides.
How does Double Corner differ from the standard Vista?

The standard Vista is installed against two fixed walls. The Double Corner version requires only one fixed wall and uses more glazing, giving it a more open, see-through appearance.
How large is the Vista Double Corner 130?

The enclosure measures 130 x 90 x 213 cm. Tylö specifies a minimum installation height of 223 cm.
Can the layout be left- or right-handed?

Yes. Tylö’s installation drawings show both left- and right-hand layouts, allowing the door and steam column position to be planned around the room.
How many fixed walls does it need?

Only one fixed wall is required. It must be prepared to wet-room standards, be straight and be capable of supporting the Stella steam column.
Is the steam generator included?

Yes. The Vista Double Corner is designed around the integrated Stella steam-shower system, so the steam generator forms part of the complete system.
Is the Elite control panel included?

Yes. The Stella system uses Tylö’s Elite control panel for steam, lighting, scheduling and connected functions.
Can it be controlled remotely?

Yes. The Stella system has built-in Wi-Fi and supports connected control through Tylö’s Elite system.
Does it include lighting?

Yes. Stella incorporates LED lighting that can be controlled through the Elite panel.
Does it need a drain?

Yes. There must be a drain inside the steam enclosure, with the floor prepared with the correct fall while remaining level beneath the Vista floor frame.
Is an optional shower tray available?

Yes. A dedicated Double Corner 130 tray is available in white or anthracite, with a built-in drain.
Does the Vista need ventilation?

For normal domestic sessions of less than two hours, Tylö says dedicated ventilation is generally not required. Longer continuous use requires an air-change rate of 10-20 m³ per person per hour.
What maintenance does the steam generator need?

The Stella system automatically empties and flushes its water reservoir, but regular descaling is still required. The appropriate interval depends on local water hardness and use.
Can the Vista Double Corner 130 be used commercially?

No. Tylö specifies the Vista steam enclosure for private use rather than public or commercial installations.
Can Hot Tubs Oxfordshire help plan the installation?

Yes. We can help with model selection, layout and the practical requirements around water, drainage, electrical supply and room preparation.

Ready to Plan Your Steam Shower?

A steam shower needs to be considered as part of the room from the outset, particularly when it comes to layout, drainage, water supply and electrical requirements. Our team can help you choose the right model and plan the installation properly.
